Vriha VMB2.0SPDP8065 – 2 HP Single & Two Phase (Double Phase) Monoblock Pump | 160-380V | 80x65 MM

Vriha VMB2.0SPDP8065 is a 2 HP single phase and two phase (double phase) centrifugal monoblock pump designed for reliable water supply, agricultural irrigation, water transfer and domestic water applications. Its key speciality is that the pump is designed to operate on both single phase and two phase (double phase) electrical supply, making it a practical choice for locations where the available power supply may vary.

This Vriha 2 HP monoblock pump operates within a 160-380 V voltage range at 50 Hz and 2880 RPM. The pump has an 80x65 MM (3x2.5 Inch) pump size and a cast iron (CI) body. It uses a mechanical seal and is designed with F Class insulation and IP44 protection.

The pump has a 12 MTR duty head and delivers 540 LPM at the duty point. Its performance range includes 730 LPM at 8 MTR head, 650 LPM at 10 MTR, 540 LPM at 12 MTR, 410 LPM at 14 MTR and 260 LPM at 16 MTR. The maximum head is 18 MTR.

The single phase and two phase (double phase) operating capability makes VMB2.0SPDP8065 different from conventional single phase monoblock pumps. It can be considered for agricultural farms, irrigation systems, water transfer, domestic water supply, tank filling, field water supply and general water circulation applications where the electrical supply condition is not always the same.

TECHNICAL SPECIFICATIONS

Model: VMB2.0SPDP8065

Pump Type: Centrifugal Monoblock Pump

Power: 2.0 HP (1.5 kW)

Phase: Single Phase & Two Phase (Double Phase)

Voltage Range: 160-380 V

Frequency: 50 Hz

Speed: 2880 RPM

Pump Size: 80x65 MM (3x2.5 Inch)

Body Material: Cast Iron (CI)

Duty Head: 12 MTR

Flow at Duty: 540 LPM

Maximum Head: 18 MTR

Insulation Class: F Class

Protection: IP44

Seal Type: Mechanical Seal

PERFORMANCE

8 MTR – 730 LPM

10 MTR – 650 LPM

12 MTR – 540 LPM

14 MTR – 410 LPM

16 MTR – 260 LPM

Maximum Head – 18 MTR

APPLICATIONS

Agricultural irrigation

Farm water supply

Field irrigation

Water supply

Water transfer

Tank filling

Domestic water supply

Garden irrigation

General water circulation

VMB2.0SPDP8065 is a Vriha 2 HP single phase and two phase (double phase) monoblock pump designed for applications requiring flexible electrical phase operation together with high-volume water pumping.
